Pain points of heavy metal wastewater treatment

Heavy metal wastewater contains harmful ions such as lead and mercury, which are highly toxic and easy to accumulate. If discharged
without treatment, it will seriously pollute the environment and threaten health

Pain point analysis

Heavy metal wastewater has a complex composition, and
   traditional treatment is difficult to be efficient and costly.

There are various treatment technologies, but a single technology
   is unable to cope with complex wastewater, making it difficult for
   companies to choose.

As discharge standards are enhanced, corporate compliance
   pressure increases dramatically and risks increase.

The technology is complex and costly, which puts high pressure on
   enterprises and makes it unbearable for small and medium-sized
   enterprises.

Necessity analysis

Effective wastewater treatment is the responsibility of the
   company in environmental protection and is essential to improving
   the environment.

Compliance treatment can improve the competitiveness of the
   enterprise, win trust, and promote the enterprise to obtain policy
   support and financing opportunities.

Advanced technologies ensure compliance with standards, prevent
   pollution accidents, and reduce legal and economic risks.

Responding to the green development strategy, wastewater
   treatment helps enterprises gain policy dividends.

Contact technical experts
Heavy Metal Wastewater Zero Discharge Process Ideas

Shangchen Environment achieves zero discharge of electroplating wastewater by adopting own patented technologies through “diversion,
classification treatment, reuse and resource recovery"

Wastewater
diversion
Classification
treatment
Wastewater
reuse
Resource
recovery
Overall idea of zero discharge process
Heavy metal high-precision
precipitation and removal system
Automatic control and management,
efficient precipitation
MVR mechanical negative pressure
evaporation crystallization system
Efficient evaporation, fractional
crystallization
Multi-stage OSMMBR biochemical
treatment technology
COD/ammonia nitrogen/SS/TP
degradation
SC-A membrane concentration
treatment system
Ultra-high multiple concentration
Heavy metal captureclassification collection
Wastewater diversion
Reuse of aborted waterConcentrated water for evaporationBiochemical degradation

Heavy metal resource recovery

Salt resource recovery

Production workshop
of enterprise
Core Technology for Zero Discharge Treatment of Heavy Metal Wastewater

99.6% of wastewater is reused by adopting the combined process of “pretreatment + OSMMBR + SPNR + MVR"
maximizing the recycling of water resources

Heavy metal high-precision
removal technology
OSMMBR system Special membrane concentration
salt doubling technology
SC-MVR evaporation crystallization and salt separation technology
Heavy metal high-precision removal technology ensures the complete removal of heavy metals by precisely controlling pH and ORP, adding chemicals, precipitation, filtration, and deep treatment.

Online monitoring and control: Automatic monitoring of pH and ORP, precise dosing.

Efficient stirring system: Fast stirring speed, reaction efficiency increased by 15
times.

Efficient sedimentation control: Corrugated inclined plate filler increases hydraulic
load and prevents plate collapse.

Efficient filtration system: Combine various filter media, 3 times the dirt holding
capacity, and long backwash intervals.

OSMMBR system can treat high-salt wastewater with salt-tolerant bacteria, retain activated sludge, and completely remove suspended solids to ensure that the effluent SS is close to zero.

High volumetric load: Strong adaptability and high-quality output water.

Small land occupation: No secondary sedimentation tank is required, small amount
of sludge.

Efficient treatment: Rremove high-salt and high-difficult-to-degrade COD
wastewater, good denitrification.

Modular design: Easy to expand, moveable, automatic management.

Long-life membrane material: modified PPSU, anti-pollution, easy to clean.

SPNR technology combines crude and refined desalination to concentrate wastewater 20-50 times, and the treated water can be directly reused in production.

It still has high desalination rate at high flow rate.

It has high mechanical strength and service life.

It is able to function at lower operating pressures.

It is less affected by factors such as pH value and temperature.

It has good chemical stability and high cost performance.

SC-MVR technology can achieve zero discharge of high-salt wastewater and salt separation and resource utilization through steam compression, which is energy-saving and efficient.

Efficient heat balance: Optimize heat energy utilization, and reduce the evaporation
cost to 40~50 yuan/ton.

High-precision salt separation: Fractional crystallization to achieve industrial-grade
by-product salt.

Fully automatic monitoring: Video monitoring and data transmission, accurate
prediction and correction.

Stable operation: Multiple technologies are adopted to ensure long-term stable
operation of the system.

Low equipment investment: High-efficiency evaporator and steam partial pressure
technology, reducing costs

Customized Wastewater Zero Discharge Solutions
  • Heavy metal industrial wastewater
    zero discharge solution
  • Electroplating wastewater zero
    discharge solution
  • Chromium-containing wastewater
    zero discharge solution
  • Surface treatment
    wastewatersolution
  • Acidic wastewater resource
    recovery solution
  • High-salt organic wastewater
    treatment solution
Cooperation Projects of Shangchen Environment
Case One Case Two Case Three
Dongguan Good View Industrial Co., Ltd.

The first electroplating wastewater zero discharge enterprise case in China

Dongguan Good View Industrial Co., Ltd. is a large and medium-sized enterprise specialized in the production of high-end handicrafts, decorations, and precision stamping parts. It has multiple process production lines such as die-casting, molds, etching, electroplating, spraying, injection molding, and packaging. It produces 35 million pieces of hardware jewelry accessories, and the total surface electroplating area is equivalent to 1.4 million square meters per year. Processing capacity.

Processing
capacity

1500m3/d

Business
mode

Environmental assessment + design + construction + operation

Treatment
effect

Since the Project was completed, it has been running stably without any wastewater being discharged, and all the produced water are recycled for production.

HEGII

The first electroplating wastewater zero discharge project in the sanitary ware industry

The wastewater zero discharge project of HEGII is the first electroplating wastewater zero discharge project in the sanitary ware industry, and is also the application project by adopting third-generation electroplating wastewater zero discharge technology of Shangchen Environment. Shangchen Environment provides overall environmental steward services in the form of “environmental assessment + design + construction + operation".

Processing
capacity

800m3/d

Business
mode

Environmental assessment + design + construction + operation

Treatment
effect

Electroplating wastewater is turned into treasure and reused in the production workshop, achieving zero wastewater discharge.

Zhejiang Environmental Protection Park

Yiwu Bao Industrial Park Environmental Protection General Contracting

Yiwu Surface Treatment Environmental Protection Industrial Park project is the first electroplating wastewater "zero discharge" environmental park in Zhejiang Province. The Park does not have a production wastewater discharge outlet, and waste gas is uniformly collected and centrally treated.

Processing
capacity

5000m3/d

Business
mode

EPC for design, procurement, construction, installation and commissioning

Treatment
effect

Various types of wastewater are recycled for production after efficient purification, achieving zero discharge of production wastewater of the Park

Strategic partners
